1932-39 Farmall McCormick-Deering F-12 & F14 Tractor Parts Catalog TC-9-B. This Parts Catalog offers a complete listing on every part on the tractor it contains exploded drawings for correct assembly and identification, part numbers, part names, descriptions and dimensions necessary for proper identification of parts, part quantities used per vehicle, model application, and the year a part was used.

* INSTANT DOWNLOAD NO WAITING
* PDF FORMAT
---------------------------------------------------------------------------
McCormick-Deering Farmall F-12 Tractor Specs

Model history
Model introduced 1932
Model discontinued 1938
Model status Discontinued
No. produced 148,690
Superseded by Farmall F-14

Engine Specification
Engine make International
Fuel type gasoline
Power hp 16 belt, 10 drawbar
Governed rpm 1400
Displacement cu in /(litre) 113 ci
No. of Cylinders 4
Bore in (mm) 3
Stroke in (mm) 4
Cooling system Water
Naturally aspirated, Turbo or Supercharged NA

Transmission Details
Transmission type sliding gear
Gearbox make International
Forward 3
Reverse 1
Drive 2-WD

General Data
Linkage Category Drawbar
Tyre Sizes (std/options)
Front 7.50-10 single (steel 23"x6" single standard)
Rear 9.00-40 (steel 54"x6" standard)

Tractor Dimensions
Length (inches/metres) 126 in
Width (inches/meters) 44 in
Height (inches/meters) 63 in
Weight (nominal) lb/kg 2700 lb
Turning circle (nominal) inches/meters 14 ft
Wheelbase 76 in

Other info
Factories Farmall Works, Rock Island, Illinois
Plow rating 1-2
Nebraska Tests No. 212
Approximate Cost new in (year) $798 (1934)

---------------------------------------------------------------------------
McCormick-Deering Farmall F-14 Tractor Specs

Model history
Model introduced 1938
Model discontinued 1939
Model status Discontinued
No. produced 31,903
Preceded by Farmall F-12
Superseded by Farmall B

Engine Specification
Engine make International
Fuel type distillate
Power hp 17 belt, 15 drawbar
Governed rpm 1650
Displacement cu in /(litre) 113 ci
No. of Cylinders 4
Bore in (mm) 3
Stroke in (mm) 4
Cooling system Water
Naturally aspirated, Turbo or Supercharged NA

Transmission Details
Transmission type sliding gear
Gearbox make International
Forward 3
Reverse 1
Drive 2-WD

General Data
Linkage Category Drawbar
Tyre Sizes (std/options)
Front 5.00-15 4-ply (steel 22.5"x4" standard)
Rear 9.00-40 6-ply (steel 54"x6" standard)

Tractor Dimensions
Length (inches/metres) 125 in
Height (inches/meters) 70 in
Weight (nominal) lb/kg 2800 lb
Turning circle (nominal) inches/meters 14 ft
Wheelbase 77 in

Other info
Factories Farmall Works, Rock Island, Illinois
Plow rating 2
Nebraska Tests No. 297
Approximate Cost new in (year) $780 (1939)

---
