14.95 USD

1939-1952 Farmall MD & MDV Tractor Owners/Operators Manual the Owners Manual is the same exact manual received when the tractor was new, it covers all aspects of your tractor. Some of the subjects covered are Maintenance Procedures, Lubrication, Special Attachments, Specifications & Operating your Tractor.

* INSTANT DOWNLOAD NO WAITING
* PDF FORMAT

---------------------------------------------------------------------------------------------
Farmall MD Tractor Specs

Model introduced 1941
Model discontinued 1952
Model status Discontinued
Preceded by New model
Superseded by McCormick Farmall Super MD

Engine Specification
Engine make International
Engine model D-248
Fuel type diesel
Power hp 37 belt, 33 drawbar
Governed rpm 1450
Displacement cu in /(litre) 248 ci
No. of Cylinders 4
Bore in (mm) 3.875 in
Stroke in (mm) 5.25 in
Cooling system water
Naturally aspirated, Turbo or Supercharged NA

Transmission Details
Transmission type sliding gear
Gearbox make International
Forward 5
Reverse 1
Drive 2-WD

General Data
Linkage Category drawbar
Tyre Sizes (std/options)
Front 6.00-16 4-ply
Rear 12-38 6-ply

Tractor Dimensions
Length (inches/metres) 133 in
Width (inches/meters) 85 in
Height (inches/meters) 76 in
Weight (nominal) lb/kg 4745 lb
Turning circle (nominal) inches/meters 17 ft
Wheelbase 90 in

Other info
Factories Tractor Works, Chicago, Illinois
Plow rating 3-14"
Nebraska Tests No. 368
Approximate Cost new in (year) $3335 (1952)

---------------------------------------------------------------------------------------------
Farmall MDV Tractor Specs

Model history
Model introduced 1945
Model discontinued 1952
Model status Discontinued
Preceded by New Model
Superseded by McCormick Farmall Super MDV

Engine Specification
Engine make International
Engine model D-248
Fuel type diesel
Power hp 37 belt, 33 drawbar
Governed rpm 1450
Displacement cu in /(litre) 248 ci
No. of Cylinders 4
Bore in (mm) 3.875 in
Stroke in (mm) 5.25 in
Cooling system water
Naturally aspirated, Turbo or Supercharged NA

Transmission Details
Transmission type sliding gear
Gearbox make International
Forward 5
Reverse 1
Drive 2-WD
General Data
Linkage Category drawbar
Tyre Sizes (std/options)
Front 6.00-20 4-ply
Rear 10.00-36 6-ply

Tractor Dimensions
Length (inches/metres) 148 in
Width (inches/meters) 86 in
Height (inches/meters) 90 in
Weight (nominal) lb/kg 5835 lb
Turning circle (nominal) inches/meters 25 ft
Wheelbase 93 in

Other info
Factories Tractor Works, Chicago, Illinois
Plow rating 3-14"
Nebraska Tests No. 368

---

Keywords: farmall md mdv owners;farmall tractors
File Size: 9.1 MBytes
