14.95 USD

1947-54 Farmall Super A & AV Owners/Operators Manual the Owners Manual is the same exact manual received when the tractor was new, it covers all aspects of your tractor. Some of the subjects covered are Maintenance Procedures, Lubrication, Special Attachments, Specifications & Operating your Tractor.

* INSTANT DOWNLOAD NO WAITING
* PDF FORMAT

---------------------------------------------------------------------------
Farmall Super A Specs

Model history
Model introduced 1947
Model discontinued 1954
Model status Discontinued
No. produced 105,679
Preceded by McCormick-Deering Farmall A
Superseded by McCormick Farmall Super A-1

Engine Specification
Engine make International
Engine model C-113
Fuel type gasoline
Power hp 18 belt, 16 drawbar
Governed rpm 1400
Displacement cu in /(litre) 113 ci
No. of Cylinders 4
Bore in (mm) 3 in
Stroke in (mm) 4 in
Cooling system water
Naturally aspirated, Turbo or Supercharged NA

Transmission Details
Transmission type sliding gear
Gearbox make International
Forward 4
Reverse 1
Drive 2-WD

General Data
Linkage Category drawbar
Tyre Sizes (std/options)
Front 5.00-15 4-ply
Rear 12.4-24 4-ply

Tractor Dimensions
Length (inches/metres) 106 in
Width (inches/meters) 56 in
Height (inches/meters) 64 in
Weight (nominal) lb/kg 2385 lb
Turning circle (nominal) inches/meters 17 ft
Wheelbase 71 in

Other info
Factories Tractor Works, Chicago, Illinois
Plow rating 1-16"
Approximate Cost new in (year) $1400 (1954)

---------------------------------------------------------------------------
Farmall Super AV Tractor Specifications

Model history
Model introduced 1948
Model discontinued 1954
Model status Discontinued
Preceded by McCormick-Deering Farmall AV
Superseded by McCormick Farmall Super AV-1

Engine Specification
Engine make International
Engine model C-113
Fuel type gasoline
Power hp 18 belt, 16 drawbar
Governed rpm 1400
Displacement cu in /(litre) 113 ci
No. of Cylinders 4
Bore in (mm) 3 in
Stroke in (mm) 4 in
Cooling system water
Naturally aspirated, Turbo or Supercharged NA

Transmission Details
Transmission type sliding gear
Gearbox make International
Forward 4
Reverse 1
Drive 2-WD

General Data
Linkage Category drawbar
Tyre Sizes (std/options)
Front 4.00-19 4-ply
Rear 8-36 4-ply

Tractor Dimensions
Length (inches/metres) 115 in
Width (inches/meters) 61 in
Height (inches/meters) 71 in
Weight (nominal) lb/kg 2825 lb
Turning circle (nominal) inches/meters 17.5 ft
Wheelbase 72 in

Other info
Factories Tractor Works, Chicago, Illinois
Plow rating 1-16"

---

Keywords: farmall super a av;ih tractor;operators;owners
File Size: 66.5 MBytes
